Display
Size	7”
Resolution	1920 x 1200
Brightness	500cd/m²
Aspect ratio	16:10
Contrast	1000:1
Viewing Angle	170°/170°(H/V)
Video Input
SDI	1×3G
HDMI	1×HDMI 1.4
Video Loop Output
SDI	1×3G
HDMI	1×HDMI 1.4
Supported In / Out Formats
SDI	720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60
HDMI	720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60，2160p 24/25/30
Audio In/Out (48kHz PCM Audio)
SDI	12ch 48kHz 24-bit
HDMI	2ch 24-bit
Ear Jack	3.5mm - 2ch 48kHz 24-bit
Built-in Speakers	1
Power
Operating power	≤12W
DC In	DC 7-24V
Compatible batteries	NP-F Series
Input voltage (battery)	7.2V nominal
Environment
Operating Temperature	0℃~50℃
Storage Temperature	-20℃~60℃
Other
Dimension(LWD)	182×124×22mm
Weight	405g
